Description
Output Power Stereo (RMS) – 2 x 800W @ 8 ohm
Output Power Stereo – 2 x 1280W @ 4ohm
Output Power Stereo – 2 x 1920W @ 2ohm
Bridge Mode (RMS) – 1600W @ 16ohm
Bridge Mode (RMS) – 2640W @ 8ohm
Bridge Mode (RMS) – 3360W @ 4ohm
Frequency Response – 10Hz-20KHz/±0.35dB
THD+N (20Hz-20KHz) – <0.5% @ 801kHz
S/N Rate (20Hz-20 kHz) – >100dB
Crosstalk (1KHz) – >70dB
Slew Rate – >30 ν/με
Damping Factor – >5000 (8Ohm) 20Hz to 100Hz
Voltage Gain – 39.7dB (0.775V:75V)
Input Sensitivity – 0.775V,1V,1.4V,2V
Input Impedance – 10K Ω balance/20K Ω unbalance
Input Connectors – XLR Active balanced pin1 gnd/pin 2+/pin3-
Output Connectors – 2 Neutrik NL4 Sockets /2 input posts
Protection – short-circuit, DC, overload, overheat, ultrasonic, RF, voltage peak limit,
Operating Voltage – 110V/220V available
Fuse – F-12A
Power consumption (Idle) – <80W
Power consumption (Max) – <1000W
Cicuit – Class D
Dimensions (LxWxD) – 483mm×420mm×45mm (1U)
Package (L×W×D) – 580mm×478mm×73mm
Net Weight – 7Kg
Gross Weight – 8.5Kg
