Description
Output Power Stereo (RMS) – 4 x 1200W @ 8ohm
Output Power Stereo (RMS) – 4 x 1920W @ 4ohm
Output Power Stereo (RMS) – 4 x 2880W @ 2ohm
Bridge Mode (RMS) – 2 x 2400W @ 16ohm
Bridge Mode (RMS) – 2 x 3960W @ 8ohm
Bridge Mode (RMS) – 2 x 5040W @ 4ohm
Frequency Response – 10Hz-20KHz/±0.35dB
THD+N (20Hz-20KHz) – ≤0.5% @ 8Ω1kHz
S/N Rate (20Hz-20 kHz) – >100dB
Crosstalk (1KHz) – >70dB
Slew Rate – >30ν/με
Damping Factor – >3000 (8Ohm) 20Hz to 100Hz
Voltage Gain – 41.7dB (0,775V:94V)
Input Sensitivity – 0.775V,1V,1.4V,2V
Input Impedance – 10K Ω balance/20K Ω unbalance
Input Connectors – XLR Active balanced
Input Connectors – pin1 gnd/pin 2+/pin3-
Output Connectors – 4 Neutrik NL4 Sockets
Protection – short-circuit, DC, overload, overheat, ultrasonic, RF, voltage peak limit,
Operating Voltage – 110V/220V available
Fuse – F-25A
Power consumption (Idle) – <130W
Power consumption (Max) – <4000W
Cicuit – Class D
Dimensions (LxWxD) – 483mm×420mm×45mm (1U)
Package (L×W×D) – 580mm×478mm×73mm
Net Weight – 8.2Kg
Gross Weight – 9.5kg
