Description
Output Power Stereo(RMS) – 4x800W@8ohm
Output Power Stereo(RMS) – 4x1280W@4ohm
Output Power Stereo(RMS) – 4x1920W@2ohm
Bridge Mode(RMS) – 2x1600W@16ohm
Bridge Mode(RMS) – 2x2640W@8ohm
Bridge Mode(RMS) – 2x3360W@4ohm
Frequency Response – 10Hz-20KHz/±0.35dB
THD+N (20Hz-20KHz) – <0.5% @ 801kHz
S/N Rate (20Hz-20 kHz) – >100dB
Crosstalk (1KHz) – >70dB
Slew Rate – >30ν/με
Damping Factor – >3000 (8Ohm) 20Hz to 100Hz
Voltage Gain – 39.7dB (0.775V:75V)
Input Sensitivity – 0.775V, 1V, 1.4V,2V
Input Impedance – 10Κ Ω balance/ 20K Ω unbalance
Input Connectors – XLR Active balanced pin1 gnd/pin 2+/pin3
Output Connectors – 4 Neutrik NL4 Sockets
Protection – short-circuit, DC, overload, overheat, ultrasonic, RF, voltage peak limit
Operating Voltage – 110V/220V available
Fuse – F-20A
Power consumption (Idle) – <110W
Power consumption (Max) – <2000W
Circuit – Class D
Dimensions (L×W×D) – 483mm×420mm×45mm(1U)
Package (L×W×D) – 580mm×478mm×73mm
Net Weight – 8 Kg
Gross Weight – 9.5 Kg
