GLABS SP41200H AMPLIFIER

Output Power Stereo (RMS) – 4 x 1400W @ 8ohm

Output Power Stereo (RMS) – 4 x 2100W @ 4ohm

Bridge Mode (RMS) – 2 x 2800W 16ohm

Bridge Mode (RMS) – 2 x 4200W @ 8ohm

Bridge Mode (RMS) – 2 x 5000W @ 4ohm

Frequency Response – 10Hz-20KHz/±0.2dB

THD+N (20Hz-20KHz) – <0.5% @ 821kHz

S/N Rate (20Hz-20 kHz) – >100dB

Crosstalk (1KHz) – >70dB

Slew Rate – >30ν/με

Damping Factor – >5000 (80hm) 20Hz to 100Hz

Voltage Gain – 42dB (0,775V:98V)

Input Sensitivity – 0.775V,1V,1.4V

Input Impedance – 10K Ω balance/20K Ω unbalance

Input Connectors – XLR Active balanced

Input Connectors – pin1 gnd/pin 2+/pin3-

Output Connectors – 4 Neutrik NL4 Sockets

Protection – short-circuit, DC, overload, overheat, ultrasonic, RF, voltage peak limit,

Operating Voltage – 110V/220V available

Fuse – F-25A

Power consumption (Idle) – <45W

Power consumption (Max) – <4500W

Cicuit – Class H

Dimensions (LxWxD) – 483mm×436mm×90mm (2U)

Package (L×W×D) – 610mm×550mm×145mm

Net Weight – 32KG

Gross Weight – 34.5kg

Description

Output Power Stereo (RMS) – 4 x 1400W @ 8ohm

Output Power Stereo (RMS) – 4 x 2100W @ 4ohm

Bridge Mode (RMS) – 2 x 2800W 16ohm

Bridge Mode (RMS) – 2 x 4200W @ 8ohm

Bridge Mode (RMS) – 2 x 5000W @ 4ohm

Frequency Response – 10Hz-20KHz/±0.2dB

THD+N (20Hz-20KHz) – <0.5% @ 821kHz

S/N Rate (20Hz-20 kHz) – >100dB

Crosstalk (1KHz) – >70dB

Slew Rate – >30ν/με

Damping Factor – >5000 (80hm) 20Hz to 100Hz

Voltage Gain – 42dB (0,775V:98V)

Input Sensitivity – 0.775V,1V,1.4V

Input Impedance – 10K Ω balance/20K Ω unbalance

Input Connectors – XLR Active balanced

Input Connectors – pin1 gnd/pin 2+/pin3-

Output Connectors – 4 Neutrik NL4 Sockets

Protection – short-circuit, DC, overload, overheat, ultrasonic, RF, voltage peak limit,

Operating Voltage – 110V/220V available

Fuse – F-25A

Power consumption (Idle) – <45W

Power consumption (Max) – <4500W

Cicuit – Class H

Dimensions (LxWxD) – 483mm×436mm×90mm (2U)

Package (L×W×D) – 610mm×550mm×145mm

Net Weight – 32KG

Gross Weight – 34.5kg
