Description
Output Power Stereo (RMS) – 4 x 1600W @ 8ohm
Output Power Stereo (RMS) – 4 x 2400W @ 4ohm
Bridge Mode (RMS) – 2 x 3200W 16ohm
Bridge Mode (RMS) – 2 x 4800W 8ohm
Bridge Mode (RMS) – 2 x 6400W @ 4ohm
Frequency Response – 10Hz-20KHz/±0.2dB
THD+N (20Hz-20KHz) – <0.5% @ 821kHz
S/N Rate (20Hz-20 kHz) – >100dB
Crosstalk (1KHz) – >70dB
Slew Rate – >30ν/με
Damping Factor – >5000 (80hm) 20Hz to 100Hz
Voltage Gain – 42.7dB (0,775V:106V)
Input Sensitivity – 0.775V,1V,1.4V
Input Impedance – 10K Ω balance/20K Ω unbalance
Input Connectors – XLR Active balanced
Input Connectors – pin1 gnd/pin 2+/pin3-
Output Connectors – 4 Neutrik NL4 Sockets
Protection – short-circuit, DC, overload, overheat, ultrasonic, RF, voltage peak limit,
Operating Voltage – 110V/220V available
Fuse – F-30A
Power consumption (Idle) – <50W
Power consumption (Max) – <5500W
Cicuit – Class H
Dimensions (LxWxD) – 483mm×436mm×90mm (2U)
Package (L×W×D) – 610mm×550mm×145mm
Net Weight – 33KG
Gross Weight – 35.5kg
