Description
Output Power Stereo (RMS) – 2 x 650W @ 8ohm
Output Power Stereo (RMS) – 2 x 975W @ 4ohm
Output Power Stereo (RMS) – 2 x 1300W @ 2ohm
Bridge Mode (RMS) – 1300W @ 16ohm
Bridge Mode (RMS) – 1950W @ 8ohm
Bridge Mode (RMS) – 2600W @ 4ohm
Frequency Response – 10Hz-20KHz/±0.2dB
THD+N (20Hz-20KHz) – <0.5% @ 821kHz
S/N Rate (20Hz-20 kHz) – >100dB
Crosstalk (1KHz) – >70dB
Slew Rate – >30ν/με
Damping Factor – >5000 (80hm) 20Hz to 100Hz
Voltage Gain – 39.4dB (0.775V:72.5V
Input Sensitivity – 0.775V,1V,1.4V
Input Impedance – 10K Ω balance/20K Ω unbalance
Input Connectors – XLR Active balanced
Input Connectors – pin1 gnd/pin 2+/pin3-
Output Connectors – 4 Neutrik NL4 Sockets
Protection – short-circuit, DC, overload, overheat, ultrasonic, RF, voltage peak limit,
Operating Voltage – 110V/220V available
Fuse – F-10A
Power consumption (Idle) – <30W
Power consumption (Max) – <800W
Cicuit – Class AB
Dimensions (LxWxD) – 483mm×350mm×90mm (2U)
Package (L×W×D) – 580mm×470mm×145mm
Net Weight – 17.5KG
Gross Weight – 20kg
