Description
Output Power Stereo (RMS) – 2 x 850W @ 8ohm
Output Power Stereo (RMS) – 2 x 1275W @ 4ohm
Output Power Stereo (RMS) – 2 x 1700W @ 2ohm
Bridge Mode (RMS) – 1700W @ 16ohm
Bridge Mode (RMS) – 2550W @ 8ohm
Bridge Mode (RMS) – 3400W @ 4ohm
Frequency Response – 10Hz-20KHz/±0.2dB
THD+N (20Hz-20KHz) – <0.5% @ 821kHz
S/N Rate (20Hz-20 kHz) – >100dB
Crosstalk (1KHz) – >70dB
Slew Rate – >30ν/με
Damping Factor – >5000 (80hm) 20Hz to 100Hz
Voltage Gain – 40.5dB (0,775V:82.5V
Input Sensitivity – 0.775V,1V,1.4V
Input Impedance – 10K Ω balance/20K Ω unbalance
Input Connectors – XLR Active balanced
Input Connectors – pin1 gnd/pin 2+/pin3-
Output Connectors – 4 Neutrik NL4 Sockets
Protection – short-circuit, DC, overload, overheat, ultrasonic, RF, voltage peak limit,
Operating Voltage – 110V/220V available
Fuse – F-15A
Power consumption (Idle) – <40W
Power consumption (Max) – <100W
Cicuit – Class H
Dimensions (LxWxD) – 483mm×436mm×90mm (2U)
Package (L×W×D) – 610mm×550mm×145mm
Net Weight – 24.5KG
Gross Weight – 27kg
