Description
Output Power Stereo (RMS) – 4x2100W @ 8ohm
Output Power Stereo (RMS) – 4x3360W @ 4ohm
Output Power Stereo (RMS) – 4 x 5040W 2ohm
Bridge Mode (RMS) – 2x4200W @ 16ohm
Bridge Mode (RMS) – 2x 6930W @ 8ohm
Bridge Mode (RMS) – 2x8820W @ 4ohm
Frequency Response – 10Hz – 20KHz / ±0.35dB
THD+N (20Hz-20KHz – <0.5% @ 8Ω1kHz
S/N Rate (20Hz-20 kHz) – >102dB
Crosstalk (1KHz) – >70dB
Slew Rate – >30ν/με
Damping Factor – >5000 (8Ohm) 20Hz to 100Hz
Voltage Gain – 45.5dB (0,775V:130V)
Input Sensitivity – 0.775V,1V,1.4V
Input Impedance – 10K Ω balance/ 20K Ω unbalance
Input Connectors – XLR Active balanced pin1 gnd/pin 2+/pin3-
Output Connectors – 2 Neutrik NL4 Sockets / 2 input posts
Protection – short-circuit, DC, overload, overheat, ultrasonic, RF, voltage peak limit,
Operating Voltage – 110V/220V available
Fuse – F-20A*2
Power consumption (Idle) – <155W
Power consumption (Max) – <8500W
Cicuit – Class D
Dimensions (L×W×D) – 500mm×483mm×45mm (IU)
Package (L×W×D) – 655mm×630mm×130mm
Net Weight – 13Kg
Gross Weight – 15.5Kg
